UCFB - F Seal Bearings
Heavy Duty Housing
F Seal
Bearings
HIGH temperature
HIGH RPM
Product Detail
201 To 218 Series
Metric Bore Size : 12MM - 90MM | Inch Bore Sise : 1/2 Inch - 3 inch
| Bearing | |
|---|---|
| Make | PRECI-MAX® [PMX™] |
| Material | 100 CR6/SAE 52100 Imported |
| Rpm | 1400 to 4000 RPM |
| Seal Type | F Seal (White) Metal |
| Ball Grade Quality | G10 Q |
| Quality | P0 100% ZV1 |
| Grease Operating Temperature | -30° ~ 180° C |
| Grease Dropping Point | 290° C |
| Seal Quality | Temperature and Water Resistant with Proper Fitment |
| Housing | |
|---|---|
| Weight | Heavy Duty |
| Material Grade | FG200 |
| Hardness | 160 to 170 HB |
| Material Process | Induction Casting, Greensand |
| Colour | Grey/powder Coated |
| Face | VMC/CNC Turning |
| Grease Nipple Size | M6 X 1, M8 X 1 |
| Grease Nipple Material | MS |
| Grease Nipple Cap Material | Virgin Red Colour |
Cast-Iron Three-Bolt Flanged Bracket Units Units
UCFB Industrial Series
- The UCFB Three-bolt flanged bracket units uses a popular set screw locking mechanism and is suggested for industrial applications where normal loads are encountered.
- The set screw mounting feature is ideal for reversing load applications.
- Bearing prelubricated and ready for immediate installation.
- The wide inner ring provides effective shaft support for a broad range of industrial applications. The positive contact of the land-riding bonded nitrile seal helps protect against harmful contaminations and retains lubricant under severe operating conditions.
- An external steel flinger provides additional protection from contamination.
- The UCFB-serias features superfinished raceway, grade-10 ball for smooth running and low noise operation.
- The F seal design is well-suited for applications involving wet or dirty environmets.
- UCFB-series wide inner ring ball bearings have spherical outside diameters for use in housing with corresponding spherical inside surface to compensate for shaft misalignment.
